Wide range of flow detection switches and float switches from leading UK manufacturer Cynergy3, well known for excellent quality and reliability. Utilising Cynergy3's own reed relay technology, the flow switch range includes inline and paddle options as well as non-invasive ultrasonic flow meters. The float switches are available in vertical and horizontal configurations, as well as a cable-end option.
Can't find what you're looking for? Majority of the models offered can be customised to your requirements - talk to our technical sales team: Contact us
The FS15 series of normally open flow switches by Cynergy3 utilises a fixed reed switch with a low flow restriction and a moving magnet to enable accurate flow detection, while ensuring minimal fluid flow restriction. These inline switches are designed for operation in liquid flow systems with pressure of up to 10 bar (not suitable for systems containing significant amount of solid particles) and come in 15mm tube size with a low-flow version available. The FS15 series flow switches can be operated in temperatures of up to 85°C and are WRAS approved for use in cold and hot water up to 60°C.
Customisation is available on this product - speak to our technical sales team to discuss your requirement.
The below table gives the full specifications for each resistor model available including the Cynergy3 FS15 series:
£0.00 Ex Tax: £0.00
The FS22 series of normally open flow switches by Cynergy3 utilises a fixed reed switch with a low flow restriction and a moving magnet to enable accurate flow detection, while ensuring minimal fluid flow restriction. These inline switches are designed for operation in liquid flow systems with pressure of up to 10 bar (not suitable for systems containing significant amount of solid particles) and come in 22mm tube size with a low-flow version available. The FS15 series flow switches can be operated in temperatures of up to 85°C and are WRAS approved for use in cold and hot water up to 60°C.
Customisation is available on this product - speak to our technical sales team to discuss your requirement.
The below table gives the full specifications for each resistor model available including the Cynergy3 FS22 series:
£0.00 Ex Tax: £0.00
The LITTLE-EX series of cable end float switches by Cynergy3 utilises a self-cleaning switching element to enable switching insensitive to humidity or condensation and hence use in widely fluctuating temperatures. These float switches are ATEX Ex II 1 G Ex ia IIC T6 certified and designed for use in hazardous areas. The switch is housed within a high density polyethylene floating body (please refer to the Chemical compatibility chart in Technical library) with centre of gravity carefully positioned near the cable entry. The LITTLE-EX series is supplied with 5m, 10m or 20m length of cable and can be operated in temperatures between -20°C and +40°C.
Typical applications for the Cynergy3 LITTLE-EX float switches include:
The below table gives the full specifications for each resistor model available including the Cynergy3 LITTLE-EX series:
£0.00 Ex Tax: £0.00
The MS series of cable end float switches by Cynergy3 utilises a microswitch element activated by a moving stainless steel ball with lifetime of 200,000 operations. The switch is hermetically sealed within a HDPE casing filled with non-hygroscopic closed-cell polyurethane, enabling it to work as much as 100m deep in water. The MS series features a selection of contact forms (n/o, n/c and c/o), direct switching power and protective earth conductor included as standard (except for c/o versions). The switching element is UL, VDE and CENELEC approved. The switches are supplied with 5m length of PVC or PUR (suitable for use in fuel oils) cable with and can be operated in temperatures between 0°C and +45°C.
Typical applications for the Cynergy3 MS series of float switches include:
The below table gives the full specifications for each resistor model available including the Cynergy3 MS series:
£0.00 Ex Tax: £0.00
The MS series of cable end float switches by Cynergy3 utilises a microswitch element activated by a moving stainless steel ball with lifetime of 200,000 operations. The switch is hermetically sealed within a HDPE casing filled with non-hygroscopic closed-cell polyurethane, enabling it to work as much as 100m deep in water. The MS series features a selection of contact forms (n/o, n/c and c/o), direct switching power and protective earth conductor included as standard (except for c/o versions). The switching element is UL, VDE and CENELEC approved. The switches are supplied with 5m length of WRAS approved cable with and can be operated in temperatures between 0°C and +45°C (WRAS approved to +23°C).
Typical applications for the Cynergy3 MS series of float switches include:
The below table gives the full specifications for each resistor model available including the Cynergy3 MS series:
£0.00 Ex Tax: £0.00
The OLS2 series of low cost optical float switch liquid level sensors offers high reliability, single point liquid level detection utilising infra-red emitter and detector aligned accurately within a cone to give good optical coupling when the sensor is positioned in the air. In presence of liquid this coupling is disrupted triggering the sensor. Transistor output enables configuration for various applications. The OLS2 series is resistant to false triggering due to foaming, and is available as high or low output version and in standard (-25° to +80°C) or extended (-40°C to +125°C) temperature range.
Typical applications for the Cynergy3 OLS2 liquid level sensor series include:
Customisation is available on this product - speak to our technical sales team to discuss your requirement.
The below table gives the full specifications for the Cynergy3 OLS2 series:
£0.00 Ex Tax: £0.00
The RSF43 nylon float switches are part of the RSF40 series of compact internal fittings. It offers a number of options including choice of maximum power (25vA or 100VA) and option of flying leads or M12 connector. The switch action may be reversed by rotating the switch by 180°. The RSF43 float switches come with nitrile gasket as standard, are WRAS approved and can be operated in temperature range between -20°C and +75°C.
Typical applications for the Cynergy3 RSF40 series of float switches include:
Customisation is available on this product - speak to our technical sales team to discuss your requirement.
The below table gives the full specifications for the Cynergy3 RSF40 series including the RSF43 switches:
£0.00 Ex Tax: £0.00
The RSF44 polypropylene (PP) float switches are part of the RSF40 series of compact internal fittings. It offers a number of options including choice of maximum power (25VA or 100VA) and option of flying leads or M12 connector. The switch action may be reversed by rotating the switch by 180°. The RSF44 float switches come with nitrile gasket as standard, are WRAS and NSF approved and can be operated in temperature range between -20°C and +100°C.
Typical applications for the Cynergy3 RSF40 series of float switches include:
Customisation is available on this product - speak to our technical sales team to discuss your requirement.
The below table gives the full specifications for the Cynergy3 RSF40 series including the RSF44 switches:
£0.00 Ex Tax: £0.00
The RSF46 Polyphenylene Sulphide (PPS) float switches are part of the RSF40 series of compact internal fittings. It offers a number of options including choice of maximum power (25VA or 100VA) and option of flying leads or M12 connector. The switch action may be reversed by rotating the switch by 180°. The RSF46 float switches come with nitrile gasket as standard, are UL and NSF approved (and WRAS approved when used with Nitrile gasket) and can be operated in temperature range between -10°C and +120°C.
Typical applications for the Cynergy3 RSF40 series of float switches include:
Customisation is available on this product - speak to our technical sales team to discuss your requirement.
The below table gives the full specifications for the Cynergy3 RSF40 series including the RSF46 switches:
£0.00 Ex Tax: £0.00
The RSF47 Polyvinylidene Fluoride (PVDF) float switches are part of the RSF40 series of compact internal fittings. It offers a number of options including choice of maximum power (25VA or 100VA) and option of flying leads or M12 connector. The switch action may be reversed by rotating the switch by 180°. The RSF47 float switches come with nitrile gasket as standard, are UL and NSF approved and can be operated in temperature range between -10°C and +105°C.
Typical applications for the Cynergy3 RSF40 series of float switches include:
Customisation is available on this product - speak to our technical sales team to discuss your requirement.
The below table gives the full specifications for the Cynergy3 RSF40 series including the RSF47 switches:
£0.00 Ex Tax: £0.00
The RSF48 polypropylene (PP) float switches are part of the RSF40 series of compact internal fittings. It offers a number of options including choice of maximum power (25VA or 100VA) and option of flying leads or M12 connector. The switch action may be reversed by rotating the switch by 180°. The RSF48 float switches come with nitrile gasket as standard, are UL approved and can be operated in temperature range between -20°C and +100°C.
Typical applications for the Cynergy3 RSF40 series of float switches include:
Customisation is available on this product - speak to our technical sales team to discuss your requirement.
The below table gives the full specifications for the Cynergy3 RSF40 series including the RSF48 switches:
£0.00 Ex Tax: £0.00
